| PERFORMANCE SPECIFICATIONS: | |
| DC Energy | 8kWh |
| Voltage Range | 43.2Vdc to 60.8Vdc |
| DC Voltage (Nominal) | 48Vdc |
| Internal Resistance | <4 mΩ |
| CELL SPECIFICATIONS | |
| Technology | Encapsulated Cell |
| Nominal Cell Voltage | 6.4~6.6Vdc / Cell (Encapsulated) 1/2 + 0.12V Envelope |
| CHARGE CHARACTERISTICS | |
| Maximum Charge Current | 170A (~1 C) |
| Charging Method | CC/CP/VP |
| DISCHARGE SPECIFICATIONS | |
| Maximum Discharge Current | 170A (~1 C) |
| Discharging Method | CC/CP/VP |
| SMART FEATURES: | |
| Communication | CANBUS , RS232, RS485 |
| Alarm | Buzzer alarm in the event of Over/under-Voltage, Over-Current and Over Temperature |
| Dry Contact Output | Programmable Dry Contacts |
| SAFETY PERFORMANCE | |
| Short Circuit Protection | Electronic Switching, Terminal Cut-off |
| Over/under Voltage | Electronic Switching, Terminal Cut-off |
| Over Current | Electronic Switching, Terminal Cut-off |
| Over temperature | Electronic Switching, Terminal Cut-off |
| MECHANICAL SPECIFICATIONS | |
| Dimensions (W x H x D) mm | 482 x 134 x 568 |
| Weight (kg) | 43 kgs |
| Module Casing Material | GI Powdered |
| Terminal Post | 300A Terminal Post |
| ENVIRONMENT SPECIFICATIONS | |
| Operating Temperature Range | -30ºC ~ +70ºC |
| Operating Humidity | Non-Condensing |
| MODULE SERVICE LIFE | |
| Projected Cycle Life | 500,000 Cycles |
| Projected Calender Life | 25 Years |
| Shelf Life | 10 Years |
| Warehousing | Can be stored at any SOC without affecting cycle life |
| PRECAUTIONS | |
| Alarm | In case of alarm, immediately rectify/attend to the cause of the alarm. |
| Physical Damage | In case the Module is physically damaged due to any event, do not install and energize the Module under any circumstances and contact your Reseller or After Sales Support. |
| Short Circuit | Ensure precautions to prevent short-circuit under all circumstances |
| Galvanic Isolation | When connecting to external devices ensure that galvanic isolation of the external device(s) does not exceed 1000V. |
| Series Connection | All Modules must be at 100% SOC before connecting in series. Do not Connect in series without controller. |
| Parallel Connection | All modules must be at 100% SOC before connecting in parallel. There is no limit on the number modules that can be connected in parallel. |
| Series - Parallel Connection | Modules cannot be connected in series-parallel combination under any circumstance. |
- The temperature range indicates the range in which the encapsulated cells can operate. The performance of the cells may vary if they are continuously operated outside a temperature range of -20ºC to 55ºC, and/or at C-rates higher than the maximum charge/discharge rate specified in this spec sheet. The operating temperature range of the module varies based on the application. If the module is to be operated continuously outside a temperature range of -20ºC to 55ºC, and/or at C-rates higher than the maximum charge/discharge rate specified in the spec sheet, please consult Alchemist or its Reseller prior to deploying.
- Warranty conditions will apply. Please consult your Reseller for warranty conditions applicable to your region.
- Projected life of encapsulated cells. Cycle life will vary if cycled more than 4 times a day.
- Additional terms and conditions, including a limited warranty, will apply at the time of purchase.
- Projected Calendar life of encapsulated cells from the date of first operation.
- Shelf life is the life of the module (in years) from the date it is manufactured to the time it is first operated
- Product dimensions are for reference only unless otherwise identified and may change without notice. For critical applications, please contact your reseller.
DIMENSIONS:
